ArjoHuntleigh Maxi 500 power patient lift with 2-point hanger bar

Buy now and get a free std padded loop sling w/o head support & extra 2% discount

ArjoHuntleigh Maxi 500 power patient lift with 2-point hanger bar has a feeling of safety and security, while the caregiver is able to maintain proper body posture and avoid injury.

Regular Price: $4,350.00

Special Price $4,127.00

Buy now and get extra 2% discount

Please call or email us to order the accessories separately.



ArjoHuntleigh Maxi 500 power patient lift with 2-point hanger bar combines proven lifting technology with the latest standards in safety, security and comfort for both resident/client and caregiver alike. Maxi 500 lift is compatible with a full range of head and body support slings, the battery-operated Maxi 500 allows caregivers to give their undivided attention to the resident/client during client handling routines. Maxi 500 supports one caregiver to perform safely and comfortably a wide range of everyday client transfer tasks. And, the caregiver can also raise a person who has fallen to the floor without needing to sit the resident up first. With a 500 lbs. safe working load, the Maxi 500 is able to lift and transfer the majority of resident/clients.

Maxi 500 power patient lift helps in all power-assisted procedures which can be closely controlled by the caregiver. With dual controls the caregiver can choose the most convenient solution for each task via either the handset or the mast control panel. The adjustable chassis, operated from the handset, can be easily adjusted to allow optimum access for resident/client transfers involving large chairs, wheelchairs or toilets.

Maxi 500 is available without or with scale option, enabling the caregiver to quickly weigh the resident during a transfer. Efficiently integrating weighing into transfer procedures saves time, eliminates a transfer to a fixed scale and makes the routine easier for resident/client and caregiver.

Buy now and get a free std padded loop sling w/o head support & extra 2% discount

  • Safe working load 500 lbs.
  • Available with or without scale
  • Available with a 2 point spreader bar
  • Emergency stop and emergency lowering
  • Low friction castors, the rear two with brakes
  • Ergonomic and durable handheld control unit
  • Power base, operated via the handheld control unit
  • Include two detachable batteries and battery charger
  • Slings are available in a range of different variants and sizes
  • Soft start/stop circuitry increases resident/client comfort and cooperation
  • Dual controls, allow caregiver to operate lift with or without handheld control unit

Weight Capacity of ArjoHuntleigh Lift Slings

Sling use Disclaimer: Please note that we recommend only to use the recommended brand slings with your Patient lifts, we do not guarantee compatibility of other sling brands with your lift model.

Services available:
  • resna certified assistive technology supplier (ATS);
  • product trials; delivery; setup and fitting services available for clients in our local service area


Additional Info

Model KM560001
Brand ArjoHuntleigh Homecare
Technical Specifications
ArjoHuntleigh Maxi 500 power patient lift
Maximum safe working load 500 lbs.
Total weight 116.5 lbs.
Total lift height 52 ½"
Lifting height 25" - 72"
Height of chassis 4⅜"
External width legs closed 25"
Internal width legs open 35¾"
Battery 24V 4Ah
Protection class Handset - IP67
Lifter - IPX4
