Weight limit |
310 lbs. |
310 lbs. |
310 lbs. |
Weight of basic unit |
49 lbs. |
49 lbs. |
49 lbs. |
Overall width (including hand rims) |
23.5" |
25.5" |
27.5" |
Width between arm rests |
16.25" |
18.25" |
20.25" |
Under seat width clearance at axle |
12.625" |
14.625" |
16.625" |
Under seat width clearance at axle plate |
14.125" |
16.125" |
18.125" |
Under seat height clearance (short front tubes/axle plates, O" dump) |
17"-18.75" |
17"-18.75" |
17"-18.75" |
Under seat height clearance (long front tubes/axle plates, O" dump) |
19"-20.75" |
19"-20.75" |
19"- 20.75" |
Wheel diameters |
20", 22", 24" |
20", 22", 24" |
20", 22", 24" |
Minimum depth without footrests (20" wheels) |
27.5" |
29.5" |
31.5" |
Minimum depth without footrests (22" wheels) |
28.5" |
30.5" |
32.5" |
Minimum depth without footrests (24" wheels) |
29.5" |
31.5" |
33.5" |
Maximum depth without footrests (20" wheels) |
30.25" |
32.25" |
34.25" |
Maximum depth without footrests (22" wheels) |
31.25" |
33.25" |
35.25" |
Maximum depth without footrests (24" wheels) |
32.25" |
34.25" |
36.25" |
Maximum dimensions |
23.5"x32.25"x42" |
25.5"x34.25"x42" |
27.5"x36.25"x42" |
Footplate dimensions (single piece fixed/adjustable) |
9.5"x8.438" |
11.5" x 8.438" |
13.5"x8.438" |
Footplate dimensions (gooseneck) |
5.875"x8.438"
6.875"x8.438"
7.875"x8.438" |
5.875"x8.438"
6.875"x8.438"
7.875"x8.438" |
5.875"x8.438"
6.875"x8.438"
7.875"x8.438" |
Footplate dimensions (flip-up) |
4.25"x8.438"
5.25"x8.438"
6.25"x8.438" |
4.25"x8.438"
5.25"x8.438"
6.25"x8.438" |
4.25"x8.438"
5.25"x8.438"
6.25"x8.438" |
Lateral support pad size |
5"x3"x1" |
5"x3"x1" |
5"x3"x1" |
Lateral support adjustment range |
0"-16" |
0"-16" |
0"-16" |
Seat height range from floor to top of seat |
20"-23.75" |
20"-23.75" |
20"-23.75" |
Maximum seat dump |
1.5" |
1.5" |
1.5" |
Seat fore/aft adjustment |
2" |
2" |
2" |
Axle fore/aft adjustment |
2.75" |
2.75" |
2.75" |
Back of unit to start of the commode opening (20" wheels, seat all the way back) |
12.75" |
12.75" |
12.75" |
Back of unit to start of the commode opening (22" wheels, seat all the way back) |
13.75" |
13.75" |
13.75" |
Back of unit to start of the commode opening (24" wheels, seat all the way back) |
14.75" |
14.75" |
14.75" |
Turning diameter |
22" |
23.5" |
25" |
Armrest height from top of seat |
5.5"-12" |
5.5"-12" |
5.5"-12" |
Leg rest range (single piece fixed/adjustable, short front tubes) |
15.75"-17.75" |
15.75"-17.75" |
15.75"-17.75" |
Leg rest range (single piece fixed/adjustable, long front tubes) |
17.75"-19.75" |
17.75"-19.75" |
17.75"-19.75" |
Leg rest range (gooseneck, short front tubes) |
15"-23" |
15"-23" |
15"-23" |
Leg rest range (gooseneck, long front tubes) |
15"-25" |
15"-25" |
15"-25" |
Leg rest range (flip-up, short front tubes) |
15.5"-17.5" |
15.5"- 17.5" |
15.5"-17.5" |
Leg rest range (flip-up, long front tubes) |
17.5"-19.5" |
17.5"- 19.5" |
17.5"-19.5" |
Back height from top of seat (O" dump) |
7.75"-16" |
7.75"-16" |
7.75"-16" |
Gap between top of seat and bottom of back (O" dump) |
0"-8.25" |
0"-8.25" |
0"-8.25" |
Back angles with angle-adjustable back |
0°, 7°, 14° |
0°, 7°, 14° |
0°, 7°, 14° |
Back angle with fixed back |
7° |
7° |
7° |
Under seat height clearance (short front tubes/axle plates, without commode pan, O" dump) |
17"-18.75" |
17"-18.75" |
17"-18.75" |
Under seat height clearance (long front tubes/axle plates, without commode pan, O" dump) |
19"- 20.75" |
19"-20.75" |
19"-20.75" |
Under seat height clearance (short front tubes, 011 dumo, flush mount) |
10.25"-14" |
10.25"-14" |
10.25"-14" |
Under seat height clearance (long front tubes, O" dump, flush mount) |
12.25"-16" |
12.25"-16" |
12.25"-16" |
