Arjo Concerto pediatric shower trolley- hydraulic
Features
Arjo Concerto pediatric shower trolley - Hydraulic helps to facilitate efficient showering and hygiene care routines for individuals with mobility level E, who need to remain in a lying position. Concerto pediatric shower trolley are height-adjustable, allows the caregiver to reach their preferred working height. Concerto shower trolley can be used to collect a patient or resident from the bedside via lateral transfer, or with range of arjo ceiling lifters and passive floor lifters. Once securely placed in the shower trolley, the patient or resident may then be transported directly to the shower and back without the need for manual lifting, thus reducing workload for the caregiver.
Height-adjustability: Height-adjustable shower trolleys operated with hydraulic pump.
Maneuvering: Concerto come with safety brakes on all four castors. In addition, Concerto offers straight steering on two castors for transporting along corridors, and automatic horizontal leveling when lowered against a bed.
Comfort and positioning: To enhance comfort, provide support and aid in positioning the resident, Concerto come with a padded mattress, head cushion and wedge pillow. Concerto also offers a back support which is adjustable to three positions.
Side supports: Foldable side supports can be lowered to facilitate lateral transfers, and raised to provide support for the patient or resident. Once raised, they can be locked in place with double safety latches.
Cleaning and drainage: Concerto come with padded mattresses designed with recessed drains and run-off channels, as well as a drainage hose and drain plug. An integrated holder for the drainage hose keeps it tucked away during transportation. Concerto can also be tilted sideways for convenient cleaning and drying.
Size: Concerto pediatric is available in length: 63" (1600mm).
Sizing
Arjo Concerto pediatric shower trolley- hydraulic | |
Maximum safe working load | 385 lbs. |
Maximum resident/user weight | 330 lbs. |
Product weight | 163 lbs. |
Width (stretcher) | 25⅝" |
Total width (including side supports) | 29⅞" |
Total length | 63" |
Length of chassis (including wheel frame) | 39⅛" |
Maximum internal length of chassis | 32¼" |
Maximum external width of chassis | 27½" |
Minimum external width of chassis | 11⅞" |
Height of chassis | 5⅞" |
Height, top position floor to stretcher | 35" |
Height, low position floor to stretcher | 22½" |
Stroke range | 12⅝" |
Documents
Warranty
- Arjo products are warranted for a period of Two (2) years from the date of delivery.
- Parts under warranty will be covered at no cost. Any labor cost for service under warranty is not covered as per our terms of sale.
- Standard Manufacturer Terms & Conditions are applicable for Warranty of this product.
- Click here for detailed warranty
- Please call manufacturer for warranty/repair issues, medicaleshop cannot provide onsite warranty/repair services.
Please call us for specific details.
Returns
- Unfortunately hygiene items cannot be returned once opened, due to health concerns.
- Standard manufacturer terms & conditions are applicable for return policy of this product.
Please call us for specific details.
