EasyStand Evolv XT sit to stand stander
resna certified assistive technology practitioner (ATP);
please call us for product customization as per your requirements
product trials; delivery; setup and fitting services available for clients in our local service area
client measurements recommended to be submitted along with your order
special discounts available...
EasyStand evolv XT sit to stand stander is the most supportive and comfortable sit to stand stander that features over 60 options & configurations. These options, that would normally be custom modifications, allow a stander to be configured for specific needs. Evolv XT features modular design which makes it most versatile standing frame available. The base unit is functional for many users, however when more support is needed a wide variety of positioning options can be added to accommodate the most involved users. Evolv XT is designed to fit individuals from 6’0"-6’10” and up to 350 lbs.Positioning:
The optimal standing position has been perfected in the evolv XT standing frame. By strategically placing the pivot points of the stander in line with the body’s natural pivot points, options like the hip supports, lateral supports, and head support remain in place from sitting to standing, minimizing shear. When positioned correctly, the contoured seat provides a maximum over-center stretch for various body types. Evolv XT also accommodates for hip and knee contractures through proper positioning of the footplates and optional independent knee pads.Accessibility and independence:
Evolv XT sit to stand stander's open base makes independent transfers easier. A larger transfer seat or rotating seat can also be added to make transfers more manageable. To make standing pivot or lift assist transfers easier, an optional swing-away front or removable back can be added. The user can independently achieve the standing position with the manual hydraulic actuator or optional push-button power up lift.Safety and convenience:
EasyStand evolv XT standing frame provides a safe and supportive transition to standing. It allows the user to stand in three easy steps - adjust, transfer, and pump up. Both caregivers and users are more comfortable with the evolv XT because of the safe and easy lateral transfer and supportive transition to standing.Buy now & get free foot straps and seat angle locator
Product comes standard with
- Planar seat
- Transfer handles
- Black upholstery
- Flip-up knee pad
- Two 5" front wheels
- Two 5" rear locking casters
- Multi-adjustable foot plates
- Black molded tray with chest pad
- Manual hydraulic actuator with handle
|EasyStand evolv XT sit to stand stander (Basic)|
|Approximate height range||6'0" - 6'10"|
|Weight limit||350 lbs|
|Seat depth range (From seat pivot)||19" - 24"|
|Seat to footplate range (From seat pivot)||17" - 23"|
|Knee width (Center to center)||9"|
|Kneepad depth range (From seat pivot)||4.75" - 7"|
|Seat dimensions||19"W x 21.5"L|
|Standard tray size||21" x 24"|
|Tray/chest pad depth range (From seat pivot)||1" - 11"|
|Standard tray height range (From seat pivot)||14.5" - 31.5"|
|Footprint (At widest points)||29.5" x 37.5"|
|Weight of basic unit||112 lbs|
|Locking caster diameter||5"|
|Footplates - Plantar||10° in 3 increments|
|Footplates - Dorsi||10° in 3 increments|
|Footplates - Toe-out||15° in 3 increments|
Shadow tray measurement
|EasyStand evolv XT sit to stand stander (Shadow tray)|
|Standard shadow tray depth range (From back)||3.5" - 15"|
|Deep shadow tray depth range (From back)||7.5" - 19"|
|Shadow tray 10" height from seat (Acrylic tray is 1" shorter)||10"|
|Shadow tray 12" height from seat (Acrylic tray is 1" shorter)||12.25"|
|Weight of evolv with shadow||115 lbs|
|Shadow tray size||21" x 24"|
|EasyStand evolv XT sit to stand stander (Options)|
|Front swivel casters||Add 5"W to footprint|
|Adjustable/removable actuator handle range||+/- 15° from neutral|
|T-style handle - Extends (Each direction)||6"|
|Foot straps - Fits foot height of||4" - 6.5"|
|Secure foot straps- Fits foot height||4" - 6.5"|
|Seat - Size of roho insert||12" x 12"|
|Transfer seat dimensions||23"W x 21.5"L|
|Hip supports - Medium width||10" - 15"|
|Hip supports - Large width||12" - 17"|
|Hip supports pad size||4"W x 6"H|
|Independent kneepad height range (From seat pivot)||+5" to -5.25"|
|Independent kneepad depth range (From front of seat)||1" - 7.5"|
|Independent kneepad width range (Center to center)||9" - 13.5"|
|Independent kneepad size||7"W x 9"H|
|Independent kneepad roho insert size||5"W x 7.5"H|
|Clear acrylic tray size||21" x 24"|
|Oversized clear tray size||29" x 22"|
|Angle adjustable tray (Angle range)||0° - 35°|
|Large contoured chest pad (Approximate size)||9.5" x 15"|
|Low back (flat/contoured) height from seat||13"|
|High back (flat/contoured) height from seat||19"|
|Velcro positioning belt (Hip circumference)||26" - 55"|
|Positioning belt with airline buckle (Hip circumference)||26" - 55"|
|Small chest strap - Pad size||5"W x 19"L|
|Small chest strap-fits users chest measuring||30" - 46"|
|Large chest strap - Pad size||5"W x 24"L|
|Large chest strap-fits users chest measuring||34" - 54"|
|X-style chest vest - Medium||11"L x 9.5"W|
|X-style chest vest - Large||12.5"L x 10"W|
|Y-style chest vest - Medium||17.5"L x 11.5"W|
|Y-style chest vest - Large||20.5"L x 12.5"W|
|High mount chest vest bracket positions||18", 19", 20", 21" H (Above hip pivot)|
|Lateral supports - Medium width range||9" - 15"|
|Lateral supports - Large width range||12" - 18"|
|Lateral supports - Fore/aft pad adjustment||3"|
|Lateral supports - Height adjustment by swapping brackets left/right||2"|
|Lateral supports - Height adjustment via mounting bolts on the pads||2"|
|Lateral supports - Height range of lateral pad from hip pivot||4"|
|Lateral supports - Rotational setting of lateral pad via bolt mounting holes||90°, 180°, 270° or 360° position|
|Lateral support pad size||4"W x 6"H|
|Head support - Medium height range (From top of the seat to middle of headrest)||21" - 30.5"|
|Head support - Large height range (From top of the seat to middle of headrest)||24" - 33.5"|
|Head support - Depth range||3.75"|
|Head support - Fore/aft adjustment in relation to back pad||Flush with back aft to 3¾|
The warranty on the EasyStand Evolv line of standers is as follows:
- Ninety days on the control box, battery, and battery charger.
- Five years on the steel frame and two years on the hydraulic pump.
- The warranty on the optional Power Up Lift is two years on the actuator and hand pendant.
- The warranty on all other parts on the Evolv stander is ninety days.
- Parts under warranty will be covered at no cost.
- Any labor cost for service under warranty is not covered as per our terms of sale.
- Standard manufacturer terms & conditions apply for Warranty of this product.
Please call us for specific details.
- Returns must be made within 30 days of receipt of the product, with an approved Return Authorization.
- We will refund the invoiced amount less a 10% restocking fee and shipping charges, if the product is returned in like-new condition and shipping is prepaid.
- All returns must have an RA# number (returned authorization number), unauthorized returns will not be accepted.
- The products must be new, unused condition, not tampered with, in original packaging and returned at the customer's expense in the original packaging.
- If your return is not due to any manufacturing defect then the original shipping cost will be deducted from the total refund
- Custom orders are non-refundable and non-returnable.
- Standard manufacturer terms & conditions apply for Return policy of this product.
Please call us for specific details
