Pain Management Ultima Neo Advanced Multi-Mode Stimulator

Ultima Neo is an advanced multi-mode electrotherapy stimulator that combines improved TENS, EMS, Interferential, and Microcurrent. It is a dual channel device that performs the most sophisticated TENS and EMS modes with body part diagrams, as well as the most sophisticated Interferential device with sine wave technology and the most cutting edge Microcurrent mode.

Ultima Neo's ultra-slim, high-capacity lithium-ion battery is its best feature; it enables the user to use the Interferential function without being connected to the wall and offers extended battery life for the TENS/EMS and Micro modes. Included are universal lead wires and a charging system.

Package Includes:

• 4 Reusable Electrode Pads
• Lead Wires
• Batteries
• User Manual & Electrode Placement Guide
• Carrying Case

NEO TENS:

• Ch1 intensity: Up/down 20 steps of 5mA, 5.0 to 100mA into 1K(Peak value at pulse width=200‹s)
• Ch2 intensity: Up/down 20 steps of 5mA, 5.0 to 100mA into 1K(Peak value at pulse width=200‹s)
• Frequency (Hz): From 1Hz to 150Hz in steps of 1Hz
• Pulse width(uS): 50,60,70,80,90,100,110,120,130,140,150,160,170,180,190,200,210,220,230,240,250,300
• Waveform: Symmetrical bi-phasic rectangular Asymmetrical bi-phasic rectangular Mono-phasic
• Treatment timer: Continuous,15,30,45,60,90min

NEO EMS:

• Ch1 intensity: Up/down 20 steps of 5mA, 5.0 to 100mA into 1K(Peak value at pulse width=200‹s)
• Ch2 intensity: Up/down 20 steps of 5mA, 5.0 to 100mA into 1K(Peak value at pulse width=200‹s)
• Frequency (Hz): From 1Hz to 110Hz in steps of 1Hz
• Pulse width(uS): 50-400‹s in steps of 50‹s
• Waveform: Symmetrical bi-phasic rectangular Alternated bi-phasic rectangular
• Ramp Time: 0-5s in steps of 1s
• On time: 1-60s in steps of 1s
• Off time: 0-60s in steps of 1s
• Treatment timer: Continuous, 10,20, 30,45,60,90min

NEO MICRO:

• Ch1 intensity: Micro 1: (Neuro A), From 2.0mA to 72mA into 500(Peak value at pulse width=250‹s) in steps of 2.0mA Micro 2: (Neuro B), From 0.1mA to 10mA into 1k (Peak value at pulse width=2.1ms) in steps of 0.1mA
• Ch2 intensity: Micro 1: (Neuro A), From 2.0mA to 72mA into 500 (Peak value at pulse width=250‹s) in steps of 2.0mA Micro 2: (Neuro B), From 0.1mA to 10mA into 1k (Peak value at pulse width=2.1ms) in steps of 0.1mA)
• Frequency (Hz): Fixed 94Hz
• Pulse width(uS): Micro 1: Fixed 250‹s Micro 2: Fixed 2100‹s
• Waveform: Asymmetrical bi-phasic rectangular Monophasic Positive Rectangular
• Treatment timer: Continuous, 10,20,30,45,60,90min

NEO IFT:

• Ch1 intensity: Up/down 30 steps of 60mA, from 2.0mA to 60mA into 500
• Ch2 intensity: Up/down 30 steps of 60mA, from 2.0mA to 60mA into 500
• Frequency (Hz): From 4004Hz to 4160Hz in steps of 4Hz
• Pulse width(uS): 125 Microseconds for each phase
• Waveform: Symmetrical balanced Sine wave
• Treatment timer: Continuous, 10,20,30,45,60,90min
