Raz ZÜM-SP Folding Mobile Shower Commode Chair
Earn Loyalty Points
+2307Buy more to unlock extra rewards!
PayPal Pay Later
.png&w=3840&q=75){kind=small}
Free Shipping
Description
Raz Design Züm-SP is an aluminum folding frame self-propel shower commode chair available with an option of 22" or or 24" wheels with quick-release axles. Zum shower commode chair features a unique cross brace design to fit fully over a toilet for optimal alignment of the aperture with the toilet bowl. The 18" wide frame is designed to fit over most toilets with a molded vinyl back support to provide comfort to the user.
Zum-SP comes standard with:
- Fixed back
- Commode pan
- Quick-release axles
- 18"W aluminum frame
- 22" or 24" rear wheels
- Adjustable foot supports
- 18"W x 17"D molded seat
- Front dual-locking 5" casters
- Flip-up padded arm supports
Molded Seat:
- Molded contours offer pelvic stability and reduces pressure
- Soft integral-skin foam provides comfort & durability
- Available with open or bridge front
- Available sizes: 18"W x 17"D & 18"W x 20"D
Ischial Pelvic Alignment System:
- Seat locks in place for transfers
- Removes easily for cleaning
- Allows centering of the aperture (opening) around the users' ITs
- Provides 2" of fore/aft adjustment so the seat can be aligned with the pelvis
Fixed back:
- Provides fixed-height flip-up padded arm supports
- Locking armrest upgrade available (Z710)
- Includes molded vinyl back support, back angle adjustment (85°, 90°, 95°) with cane-style back posts
Adjustable Footrests:
- Swing in and out easily
- Flip-up footplate
- Removable for transfers and cleaning
- Adjust for leg length without tools
- Available in regular length 16"-20½" and extended length 18"-20½"
Adjustable Tension Fabric Back:
- Available in different back heights
- Removable for machine washing
- Polyester fabric for durability and comfort against skin
- Provides individualized trunk support for optimal positioning & comfort
Telescoping caster extension:
- Provide 4" of seat height adjustment without the use of tools
- Dropped front frame tube improves access over standard toilet bowls
Multi-position axle plates:
- Allow use of 22" or optional 24" rear wheels
- Provide up to 4" of vertical seat height and 1.5" of horizontal adjustment for optimum user/toilet bowl access
Commode pan:
- Includes a lid for splash and odor control
- Injection-molded pan is designed for function
- Fits in a standard autoclave and Arjo Tornado Washer
- Wide handle angled at 45 degrees provides better ergonomics
- Receiver brackets under seat are visible from the rear of the chair, making it easier to slide the pan into place
- Sloped front of pan moves contents toward the handle to reduce offset load, thereby making it easier to carry
Note: For custom or additional charge options required on the shower commode chair, please call for special pricing quote. Only standard shower commode chair options are shown online.
Specifications
| Raz Design Zum-SP Specifications | |
| Seat width (standard) | 18" |
| Frame Width | |
| Seat depth | 17", 20" |
| Armrest height above seat* | 8" |
| Footrest adjustment (from seat to footplate) - standard | 16" - 20.5" |
| Footrest adjustment (from seat to footplate) with extension tubes | 18" - 22.5" |
| Seat-to-floor height* | 21.5" |
| Overall width | Frame open: 25.25" |
| Frame folded: 13" | |
| Frame folded: 7.5" (back assembly & wheels removed) | |
| Overall length | With standard footrests: 40" with 22" wheels |
| For SP, rear wheels in center position: 41" with 24" wheels | |
| Clearance height under seat | With pan brackets: 17.25" |
| Without pan brackets: 17.75" | |
| Minimum Turning Radius | 56" |
| Product weight | 57 lbs. |
| Weight capacity | 352 lbs. |
| Frame Materials | – base frame: Aluminum |
| – back frame and footrests: Stainless Steel | |
| – hardware: Stainless Steel | |
*Measurements taken with standard molded seat and standard arm pads
Warranty
The manufacturer provides with the following warranty on its products to the original purchaser:
- Two year limited warranty on the frame against manufacturing defects.
- One year on all other components excluding parts subject to normal wear and tear.
- If any product is proven to be defective it will be repaired or replaced at the manufacturer's descretion.
- Parts under warranty will be covered at no cost.
- Any labor cost for service under warranty is not covered as per our terms of sale.
- Standard manufacturer terms and conditions apply to warranty of this product.
Please call us for specific details
Return
- Unfortunately hygiene items cannot be returned once opened, due to health concerns.
- Standard manufacturer terms & conditions are applicable for return policy of this product.
Please call us for specific details
FAQs
The chair is built with an aluminum and stainless steel frame and supports up to 352 lbs.
Telescoping caster extensions provide 4" of tool-free seat height adjustment. Additional seat-to-floor height kits are available.
The injection-molded commode pan has a lid for splash and odor control, fits autoclaves or Arjo Tornado washers, and the vinyl/molded seat and back are easy to clean.
The Ischial Pelvic Alignment System allows 2" of fore/aft seat adjustment, allowing precise centering of the seat aperture around the ischial tuberosities, locks in place for safe transfers, and removes easily for cleaning.
Footrests swing in or out, flip up, and remove for transfers. They adjust for leg length without tools and are available in regular or extended lengths.
Flip-up padded arms, with optional locking kits, provide safe lateral transfer support while allowing unobstructed access for the user.
